U-M research: New plastic is strong as steel, transparent

ANN ARBOR, Mich.—By mimicking a brick-and-mortar molecular structure found in seashells, University of Michigan researchers created a composite plastic that's as strong as steel but lighter and transparent.

It's made of layers of clay nanosheets and a water-soluble polymer that shares chemistry with white glue.

Nicholas A. Kotov, Engineering professor.

Engineering professor Nicholas Kotov almost dubbed it "plastic steel," but the new material isn't quite stretchy enough to earn that name. Nevertheless, he says its further development could lead to lighter, stronger armor for soldiers or police and their vehicles. It could also be used in microelectromechanical devices, microfluidics, biomedical sensors and valves and unmanned aircraft.

Kotov and other U-M faculty members are authors of a paper on this composite material, "Ultrastrong and Stiff Layered Polymer Nanocomposites," published in the Oct. 5 edition of Science.

The scientists solved a problem that has confounded engineers and scientists for decades: Individual nano-size building blocks such as nanotubes, nanosheets and nanorods are ultrastrong. But larger materials made out of bonded nano-size building blocks were comparatively weak. Until now.

"When you tried to build something you can hold in your arms, scientists had difficulties transferring the strength of individual nanosheets or nanotubes to the entire material," Kotov said. "We've demonstrated that one can achieve almost ideal transfer of stress between nanosheets and a polymer matrix."

The researchers created this new composite plastic with a machine they developed that builds materials one nanoscale layer after another.

The robotic machine consists of an arm that hovers over a wheel of vials of different liquids. In this case, the arm held a piece of glass about the size of a stick of gum on which it built the new material. The arm dipped the glass into the glue-like polymer solution and then into a liquid that was a dispersion of clay nanosheets. After those layers dried, the process repeated. It took 300 layers of each the glue-like polymer and the clay nanosheets to create a piece of this material as thick as a piece of plastic wrap.

Mother of pearl, the iridescent lining of mussel and oyster shells, is built layer-by-layer like this. It's one of the toughest natural mineral-based materials.

The glue-like polymer used in this experiment, which is polyvinyl alcohol, was as important as the layer-by-layer assembly process. The structure of the "nanoglue" and the clay nanosheets allowed the layers to form cooperative hydrogen bonds, which gives rise to what Kotov called "the Velcro effect." Such bonds, if broken, can reform easily in a new place.

The Velcro effect is one reason the material is so strong. Another is the arrangement of the nanosheets. They're stacked like bricks, in an alternating pattern.

"When you have a brick-and-mortar structure, any cracks are blunted by each interface," Kotov explained. "It's hard to replicate with nanoscale building blocks on a large scale, but that's what we've achieved."

Collaborators include: mechanical engineering professor Ellen Arruda; aerospace engineering professor Anthony Waas; chemical, materials science and biomedical engineering professor Joerg Lahann; and chemistry professor Ayyalusamy Ramamoorthy. Kotov is a professor of chemical engineering, materials science and engineering, and biomedical engineering.

The nanomechanical behavior of these materials is being modeled by professor Arruda's group; Waas and his group are working on nanomechanical behavior and applications in aviation.

The University of Michigan College of Engineering, which is ranked among the top engineering schools in the country. Michigan Engineering boasts one of the largest engineering research budgets of any public university, at more than $130 million. Michigan Engineering has 11 departments and an NSF Engineering Research Center. Within those departments and the center, there is a special emphasis on research in three emerging areas: nanotechnology and integrated microsystems; cellular and molecular biotechnology;

Anthony Waas; aerospace engineering professor.

and information technology. Michigan Engineering is seeking to raise $110 million for capital building projects and program support in these areas to further research discovery. Michigan Engineering's goal is to advance academic scholarship and market cutting-edge research to improve public health and well-being.
